KWT-X8L-25 is a large unmanned aerial vehicle (UAV) platform optimized for safety features, with sufficient power reserve, suitable for heavy load applications. In the case of single paddle failure, the flight is stable and controllable to ensure safe return. This model is suitable for mounting large equipment and occasions with higher requirements for safe flight. It is especially suitable for mounting airborne Lidar for surveying and mapping operations. It can also mount communication equipment as a wireless relay platform. This model can provide a delivery capacity of 25 kg (within a range of 10-20 kilometers).

This machine has been greatly optimized for electromagnetic compatibility, and can be used to mount electromagnetic sensitive loads. It supports matching full-frequency anti-interference modules. It can mount 10-25 kg communication equipment, such as 5G base stations, PDT base stations, and electronic jammers.

This model can switch between tethered mode and free flight mode. Cooperating with the Tethered Ground Control Unit, it can be instantly converted into a tethered drone system, which can be powered by the ground end, providing more than 8 hours of working time. This model provides mooring matching at various heights, supporting mooring altitudes of 100 meters, 200 meters, and 300 meters.

With the mooring ground terminal for power supply, it can achieve 24 hours of uninterrupted flight, and the system can be loaded by platforms such as trucks and ships. Support manual control mode and automatic control mode. In the manual control mode, the drone movement can be controlled by the joystick; in the automatic flight mode, the drone can automatically hover and the vehicle can automatically follow. The flight height can be set through the ground station, which supports one-button take-off, one-touch landing and recovery. When a moving platform (vehicle, ship, etc.) is stationary, the drone can hover above the platform. When the moving platform moves, the drone automatically follows the platform movement.
